3pcs 2CH Channel Optocoupler Isolation Relay Module 5V SCM PLC Signal Amplifier Board

.size_table_start table,.size_table_start table tr td { border:2px solid #ddd;}.size_table_start table { width: 100%; min-height: 25px; line-height: 25px; text-align: center; border-collapse: collapse;}.size_table_start,.size_table_end {clear:both;}

Structural Features:

?

1. Use Hongfa relay, stable and reliable performance;

2. Compatible with two input modes of positive control and negative control;

3. Each channel has an LED action indicator for a more intuitive understanding of product performance;

4. Each channel adopts optocoupler isolation to enhance anti-interference performance and isolation performance;

5. At the same time, the power supply and the IN control terminal are independently controlled;

6. The module adopts the standard DIN rail-type installation design, which is convenient and quick to install, firm and stable.

?

Technical Parameters:

?

1. Trigger signal: DC5V

2. Each trigger signal current: 5mA

3. Power supply voltage: DC5V

4. Each coil current: 18.8mA

5. Contact type: one normally open and one normally closed (single pole)

6. Maximum load current of each contact: 10A

7. Action time: below 12ms

8. Reset time: less than 4ms

9. Maximum switching frequency: 18000 times / hour

10. Mechanical life: more than 20 million times
