5Pcs 5A 75W Constant Current Voltage CC CV Buck Module StepDown Module DC 5V-35V Voltage and Ampere
5Pcs 5A 75W Constant Current Voltage CC CV Buck Module StepDown Module DC 5V-35V Voltage and Ampere
Regular price
$634.00 USD
Regular price
$1,056.67 USD
Sale price
$634.00 USD
Unit price
per
Couldn't load pickup availability
Descriptions:
Module nature: Asynchronous rectification, non-isolated, CC CV Buck-module Input voltage: (U-IN) DC5V~35V Output voltage: (U-OUT) DC 1.25V~32V Output current: 5A (max) above 3A to strengthen heat dissipation Output power: 75W (max) Switching frequency: 300Hz Output ripple: ripple 50mmV 20M bandwidth Load regulation rate: ±0.5% Voltage adjustment rate: ±2.5% Working current: <> Product size: 73??48.6??14.2mm Product weight: 32g Fixed aperture: ??3.8mm
Communication protocol: baud rate 9600Bps BB, CC frame header (2 bytes) ADDR module address 00, 01: 00 current read command, 01 voltage read command, 1 byte XX XX: any value (2 bytes) CRC: check (1 byte) Current return command, voltage return command
Package Included:
5 x 5A 75W Constant Current Voltage CC CV Buck Module
