FKG-DS 3.5A 5V 40V Dual-Channel Relay Controller Semiconductor Electronic Switch Aeromodelling Remot

Features:
1. With hysteresis input characteristics 2. Prevent manual operation jitter 3. Small size and light weight 4. Strong anti-interference ability 5. The output terminal is isolated from the signal input terminal
Application scope:
Contactor coil control Relay coil control Lighting control Switch signal control motor control
Rated parameters:
Model: FKG-DS Signal line input voltage: 5V-8V/DC (need to get power from the receiver) Quiescent current: 10mA (need to be taken from the receiver) Output characteristics: open-drain output 3.5A, maximum 40V withstand voltage is recommended to be used within 30V Control mode: output with hysteresis curve Features: dual-channel, relay contact, single-pole double-throw, two-channel independent control, isolation control on-off, indicator light shows relay on-off Limit control voltage: 40V/DC (MAX) Limit output current: 3.5A (MAX) Color:Blue Material: PCB+metal Size: 36.8 x 26.5 x 12mm Weight: 4.5g
Package included:
1 x FKG-DS controller
